Microprocessor pH Meter




Features:

  • Measures pH, mV and Temperature
  • 5 Point Calibration
  • 128 x 64 dots Graphical LCD Display
  • Auto Buffer Recognition Facility
  • Storage Up to 1000 Samples
  • Attachment for Serial Dot Matrix / Thermal Printer Microprocessor Based pH Meter Model 1015 is a solid state instrument designed to provide the precise pH and mV measurements. The instrument uses the latest Microprocessor technology and advanced engineering techniques so as to give enhanced accuracy and reproducibility. The system has user friendly prompts which guide you through out the measurement process.

    The system has 8 soft touch membrane type keys for ease of operation. It has facility for doing upto 5 point calibration. It has the storage facility for 999 samples, which are retained in the memory even when the system is switched OFF. Provision has also been provided for attachment of centronics dot matrix printer so that any of the stored results can be printed.

    The instrument is extremely useful for agriculture and soil analysis laboratories, swimming pools, water quality control in boiler feed water, water works department, fertilizer plants, petroleum refineries, breweries, water purification plants etc.

    pH


    Range

    -2.000 to 20.000 pH

    Resolution

    Selectable 0.1, 0.01, 0.001 pH

    Accuracy

    + 0.002 pH +1 digit

    Read Out

    128 x 64 dots Graphical LCD Display

    Calibration

    Auto & Manual with 5-points Calibration

    Auto Buffer Recognition

    1.680, 4.000, 7.000, 9.200 & 12.450 pH or User Selectable

    Relative Stability

    + 0.002 pH/Hour

    Temperature Compensation

    -5 to 110oC Auto/Manual

    mV


    Range

    0 + 1999.9 mV

    Resolution

    0.1 mV

    Accuracy

    +0.1 mV, + 1 digit

    Temperature


    Range

    -5.0 to 110oC

    Resolution

    0.1oC

    Accuracy

    +0.1oC

    Sensor

    Semi Conductor Type

    Power Supply

    12V DC using 230+10% AC Adaptor

    Printer Interface

    External Serial RS 232 Dot Matrix Printer Interface

    Accessories

    Combination pH Electrode, Temperature Probe, Buffer Tablets 4 pH & 7pH, Electrode Stand, Mains Lead, Instruction Manual, Dust Cover

    Note : Specifications are subject to change due to continuous improvements.
